AWS EventBridge: Event-Driven Architecture Patterns for Production

Event-driven architecture decouples producers from consumers — services publish events without knowing who consumes them, and consumers process events without knowing who produced them. This decoupling enables independent scaling, independent deployment, and system designs that are naturally resilient to individual component failures.

AWS EventBridge is the serverless event bus that makes event-driven architecture practical on AWS. It routes events between AWS services, SaaS applications, and your custom applications without any infrastructure to manage. Combined with Lambda and Step Functions, EventBridge forms the backbone of modern serverless systems.

Why EventBridge Over SQS or SNS

AWS offers three messaging services. Each serves a different purpose:

Choose EventBridge when:

• Events need content-based routing (route based on event fields, not just topic)
• Multiple consumers need different subsets of the same event stream
• You need built-in schema discovery and evolution
• Events come from AWS services or SaaS integrations (100+ sources supported natively)
• Cross-account or cross-Region event routing is required

Choose SQS when:

• You need guaranteed ordering (FIFO queues) or exactly-once processing
• The consumer needs to control processing rate (pull-based consumption)
• Simple point-to-point messaging without content-based routing

Choose SNS when:

• Simple fan-out to multiple subscribers (all subscribers get every message)
• You need SMS or email delivery alongside application consumers

In practice, these services complement each other. A common pattern: EventBridge routes events to different SQS queues based on content, and Lambda consumers process each queue independently.

Core Concepts

Event Buses

An event bus receives events and routes them to targets based on rules. EventBridge provides three types:

Default event bus — Receives events from AWS services automatically. CloudTrail API calls, EC2 state changes, S3 notifications, and dozens of other AWS service events arrive on the default bus without any configuration.

Custom event buses — Created for your application’s events. Isolate your application events from AWS service events for cleaner rule management and access control.

Partner event buses — Receive events from SaaS partners (Auth0, Datadog, Zendesk, PagerDuty, Stripe, Twilio, and others) without custom integration.

Best practice: Create a custom event bus per domain or bounded context in your application. This provides isolation, independent access control, and cleaner event catalogs.

Event Structure

Every EventBridge event follows a standard envelope:

{
  "version": "0",
  "id": "12345678-1234-1234-1234-123456789012",
  "source": "com.myapp.orders",
  "detail-type": "OrderPlaced",
  "account": "123456789012",
  "time": "2026-07-05T14:30:00Z",
  "region": "us-east-1",
  "resources": [],
  "detail": {
    "orderId": "ord-001",
    "customerId": "cust-123",
    "total": 99.99,
    "items": [{ "productId": "prod-001", "quantity": 2 }]
  }
}

Naming conventions:

• source — Reverse domain notation identifying the producer (com.myapp.orders)
• detail-type — Past-tense event name describing what happened (OrderPlaced, PaymentProcessed, UserRegistered)
• detail — The event payload with business data

Rules and Targets

Rules match events and route them to targets. Each rule has an event pattern (what to match) and one or more targets (where to send matching events).

Event pattern examples:

Match all order events:

{
  "source": ["com.myapp.orders"]
}

Match only high-value orders:

{
  "source": ["com.myapp.orders"],
  "detail-type": ["OrderPlaced"],
  "detail": {
    "total": [{ "numeric": [">", 1000] }]
  }
}

Match orders for specific products:

{
  "detail": {
    "items": {
      "productId": ["prod-001", "prod-002"]
    }
  }
}

Supported targets (28+):

• Lambda functions
• Step Functions state machines
• SQS queues
• SNS topics
• Kinesis Data Streams
• API Gateway endpoints
• EventBridge buses (cross-account/Region)
• CloudWatch Logs
• ECS tasks
• CodePipeline

Each rule can have up to 5 targets, enabling fan-out from a single event pattern.

Production Patterns

Pattern 1: Event-Driven Microservices

Decouple microservices by communicating through events instead of synchronous API calls:

Order Service → EventBridge → Inventory Service
                            → Payment Service
                            → Notification Service
                            → Analytics Service

The Order Service publishes an OrderPlaced event. Each downstream service has a rule matching that event and processes it independently. Adding a new consumer (e.g., a Loyalty Points Service) requires only a new rule — no changes to the Order Service.

Benefits:

• Services deploy and scale independently
• Adding consumers does not require producer changes
• Temporary consumer downtime does not affect producers
• Natural audit trail of all business events

Pattern 2: Event Replay and Archive

EventBridge Archives store events for replay — essential for debugging, testing, and recovery:

Events → EventBridge → Archive (retain 90 days)
                     → Normal targets

Replay: Archive → EventBridge → Specific target (with replay filter)

Use cases:

• Replay events through a new or fixed consumer
• Populate a new service with historical events
• Debug production issues by replaying the event sequence that caused them
• Disaster recovery — replay events to rebuild state

Configuration: Create an archive with a retention period and an optional event pattern filter. Replay specific time ranges to specific targets.

Pattern 3: Cross-Account Event Routing

In a multi-account AWS organization, events often need to flow between accounts:

Workload Account A → EventBridge → Central Event Bus (Shared Services Account)
Workload Account B → EventBridge ↗                    ↓
                                          → Security Account (audit events)
                                          → Analytics Account (business events)

Implementation:

1. Create a central custom event bus in the shared services account
2. Add a resource policy allowing workload accounts to PutEvents
3. Create rules in workload accounts with the central bus as the target
4. Create rules in the central bus to route events to consumer accounts

This pattern centralizes event routing while keeping event producers and consumers in their own accounts.

Pattern 4: API Destination (Webhook)

EventBridge API Destinations send events to external HTTP endpoints — webhooks for SaaS tools, partner APIs, or on-premises systems:

Application Events → EventBridge → API Destination → Slack webhook
                                 → API Destination → Partner API
                                 → API Destination → On-premises system

Features:

• Built-in rate limiting (requests per second)
• Connection management (API keys, OAuth, Basic auth)
• Automatic retries with exponential backoff
• Dead-letter queue for failed deliveries

Pattern 5: Scheduled Events

EventBridge Scheduler replaces CloudWatch Events for time-based triggers:

Schedule (cron/rate) → EventBridge → Lambda → Cleanup old data
                                   → Step Functions → Generate reports
                                   → ECS Task → Run batch job

EventBridge Scheduler advantages over CloudWatch Events:

• One-time schedules (not just recurring)
• Time zones support
• Flexible time windows for distributed execution
• Higher throughput (millions of schedules)

Input Transformation

EventBridge can transform events before delivering them to targets — reducing the need for Lambda functions that simply reformat data:

Original event:

{
  "detail": {
    "orderId": "ord-001",
    "customerId": "cust-123",
    "total": 99.99
  }
}

Input transformer:

{
  "inputPathsMap": {
    "orderId": "$.detail.orderId",
    "total": "$.detail.total"
  },
  "inputTemplate": "\"Order <orderId> placed for $<total>\""
}

Delivered to target:

"Order ord-001 placed for $99.99"

This is useful for sending formatted messages to SNS, Slack, or other notification targets without a Lambda function in between.

Schema Registry and Discovery

EventBridge Schema Registry automatically discovers event schemas from events flowing through your event buses:

• Auto-discovery — Enable on any event bus to automatically generate schemas from observed events
• Schema versions — Track schema evolution over time
• Code bindings — Generate TypeScript, Python, or Java classes from schemas for type-safe event handling

Best practice: Define schemas explicitly for your custom events and publish them to the registry. This serves as a contract between producers and consumers and enables code generation for consumer development.

Error Handling and Reliability

Dead-Letter Queues

Configure a dead-letter queue (SQS) on every EventBridge rule. Events that fail to deliver to the target after retries are sent to the DLQ for investigation:

EventBridge Rule → Target (Lambda) → Fails after retries → DLQ (SQS)

Without a DLQ, failed events are silently dropped after retry exhaustion. Always configure DLQs on production rules.

Retry Policy

EventBridge retries failed target invocations with configurable settings:

• Maximum age — How long to retry (default 24 hours, configurable 1 minute to 24 hours)
• Maximum retries — How many times to retry (default 185, configurable 0-185)

For time-sensitive events, reduce the maximum age. For idempotent consumers, maximize retries.

Idempotency

EventBridge guarantees at-least-once delivery — events may be delivered more than once. Every consumer must be idempotent:

• Use the event id field as a deduplication key
• Store processed event IDs in DynamoDB with a TTL
• Design operations to be safely repeatable (upsert instead of insert, set state instead of toggling)

Monitoring

Key CloudWatch Metrics

• Invocations — Events matched and sent to targets
• FailedInvocations — Events that failed to deliver
• TriggeredRules — Rules that matched at least one event
• ThrottledRules — Rules throttled due to target limits

Alarms

Set CloudWatch alarms for:

• FailedInvocations > 0 — Any delivery failure requires investigation
• InvocationRate anomaly — Unusual event volume may indicate a producer bug or attack
• DLQ message count > 0 — Events are being dropped

Cost Optimization

EventBridge pricing is simple: $1.00 per million events published to custom event buses. AWS service events on the default bus are free.

Cost reduction strategies:

• Use the default bus for AWS service events (free)
• Filter events at the source — publish only events that consumers need, not every state change
• Batch related data into fewer events where possible
• Use event patterns to filter precisely — avoid catch-all rules that invoke Lambda functions just to discard events

For a typical application publishing 10 million custom events per month, EventBridge costs $10 — far less than the operational cost of managing a self-hosted message broker.

Common Mistakes

Mistake 1: Using EventBridge for Synchronous Communication

EventBridge is asynchronous by design. If a service needs an immediate response from another service, use a direct API call. EventBridge is for workflows where the producer does not need to wait for the consumer’s result.

Mistake 2: Overly Broad Event Patterns

A rule that matches all events ({}) routes everything to a single target. This defeats the purpose of content-based routing and creates a processing bottleneck. Write precise event patterns that match only the events each consumer needs.

Mistake 3: No Schema Governance

Without schema governance, producers change event structures without coordinating with consumers, breaking downstream processing. Define event schemas, version them, and treat schema changes as API contract changes.

Mistake 4: Missing DLQs

Events that fail delivery with no DLQ are lost forever. Every production rule should have a dead-letter queue configured, and every DLQ should have a CloudWatch alarm monitoring its message count.

Getting Started

EventBridge is the natural evolution from point-to-point service communication to event-driven architecture. For serverless applications on AWS, it provides the routing, filtering, and reliability that production event-driven systems require — without any infrastructure to manage.

For event-driven architecture design and implementation, see our AWS Architecture Review or talk to our team about serverless application development.

Contact us to design your event-driven architecture →
